Transportabler Atemluftverdichter für 200 bar- 2900 PSI. Stabiler Rahmen, pulverbeschichtet, mit Transportgriffen.
Luftliterleistung 90 L/Min, 5,4 m³h, 3,17 cfm.
3-zylindriger, 3-stufiger Kompressorblock, 1.-2.- 3. Stufe mit Sicherheitsventil. Aluminium-Zylinder, teils mit Graugusslaufbuchsen, Aluminium-Kolben mit Spezialkolbenringen für hohe Lebensdauer, Freiflugkolben in letzter Stufe. 2 Kondenswasserabscheider mit Entlüftungshahn, Ölschleuderstift-Sicherheitsschmierung. Micronic-Ansaugfilter, Enddruckmanometer. 1 Füllanschluss DIN 200 bar+ INT-Adapter mit Entlüftung an 1,2 mtr. Schlauch. Triple+ Reintrocknersystem FT 100 für ca. 150 m³ = 25 Std. (@ 20°C Filterwantemperatur) reine Luft nach DIN 12021:2014. (vorausgesetzt der CO2 Wert cder Umgebungsluft liegt innerhalb der Normgrenzen).
Final pressure cut-off as standard.
Anschlussleitung 2m mit Schukostecker.
Antrieb mittels Keilriemen: Wechselstrommotor 2,2 kW, 230 V, 50/60 Hz, Geräuschentwicklung ca. 78 dbA.
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual,
Maße/Gewichte: LxBxH 71x 41x 40 cm, 48 kg.
5-year European warranty

Transportable breathing air compressor for 200/ 300 bar- 2900/4350 PSI. Sturdy frame, powder-coated, with transport handles.
Air flow rate 60-110 L/min, 3-6.6 m³h, 2.11- 3.88 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200/300 bar+ INT adapter with venting on 1.2 m hose. Triple+ pure dryer system FT 100 for approx. 150 m³ = 25 hours (@ 20°C filter wall temperature) of pure air in accordance with DIN 12021:2014 (provided the CO2 value of the ambient air is within the standard limits).
Final pressure cut-off as standard.
V-belt drive:
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual,
5-year European warranty

Transportable breathing air compressor for 200/ 300 bar- 2900/4350 PSI. Sturdy frame, powder-coated, with transport handles.
Air flow rate 60-110 L/min, 3-6.6 m³h, 2.11- 3.88 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200/300 bar+ INT adapter with venting on 1.2 m hose. Triple+ pure dryer system FT 100 for approx. 150 m³ = 25 hours (@ 20°C filter wall temperature) of pure air in accordance with DIN 12021:2014 (provided the CO2 value of the ambient air is within the standard limits).
Final pressure cut-off as standard.
V-belt drive:
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual,
5-year European warranty

Breathing air compressor
Transportable breathing air compressor, sturdy frame, powder-coated, with transport handles.
Air flow rate 150 L/min, 9 m³h, 5.3 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200/ 300 bar with venting on 1.2 m hose. Triple+ clean dryer system FT 100 for approx. 130 m³ clean air in accordance with DIN 12021:2014 (provided the value for CO2 in the intake air complies with the limit values)
Final pressure cut-off as standard.
Optionally with Airsave Basic filter saturation and service interval monitoring.
V-belt drive.
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual.
"5-year European warranty, you won't find anything comparable"

Breathing air compressor
Transportable breathing air compressor, sturdy frame, powder-coated, with transport handles.
Air flow rate 150 L/min, 9 m³h, 5.3 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200/ 300 bar with venting on 1.2 m hose. Triple+ clean dryer system FT 100 for approx. 130 m³ clean air in accordance with DIN 12021:2014 (provided the value for CO2 in the intake air complies with the limit values)
Final pressure cut-off as standard.
Optionally with Airsave Basic filter saturation and service interval monitoring.
V-belt drive.
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual.
"5-year European warranty, you won't find anything comparable"

Transportable breathing air compressor as marine version for 200 or 300 bar, stable STAINLESS STEEL frame, powder-coated, with likewise powder-coated stainless steel transport handles.
AUTO-STOP on reaching the final pressure included as standard.
Air flow rate 60-110 L/min, 3-6.6 m³h, 2.11- 3.88 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200 or 300 bar with venting on 1.2 m hose. Triple+ pure dryer system FT 100 for approx. 130 m³ of pure air in accordance with DIN 12021:2014 (provided the value for CO2 in the intake air complies with the limit values)
Optionally with Airsave Basic filter saturation and service interval monitoring.
V-belt drive:
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual.
" 5-year EUROPA guarantee, you won't find anything comparable"

Transportable breathing air compressor as marine version for 200 or 300 bar, stable STAINLESS STEEL frame, powder-coated, with likewise powder-coated stainless steel transport handles.
AUTO-STOP on reaching the final pressure included as standard.
Air flow rate 60-110 L/min, 3-6.6 m³h, 2.11- 3.88 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200 or 300 bar with venting on 1.2 m hose. Triple+ pure dryer system FT 100 for approx. 130 m³ of pure air in accordance with DIN 12021:2014 (provided the value for CO2 in the intake air complies with the limit values)
Optionally with Airsave Basic filter saturation and service interval monitoring.
V-belt drive:
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual.
" 5-year EUROPA guarantee, you won't find anything comparable"

Transportable breathing air compressor as marine version for 200 or 300 bar, stable STAINLESS STEEL frame, powder-coated, with likewise powder-coated stainless steel transport handles.
AUTO-STOP on reaching the final pressure included as standard.
Air flow rate 150 L/min, 9 m³h, 5.3 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200 or 300 bar with venting on 1.2 m hose. Triple+ pure dryer system FT 100 for approx. 130 m³ of pure air in accordance with DIN 12021:2014 (provided the value for CO2 in the intake air complies with the limit values)
Optionally with Airsave Basic filter saturation and service interval monitoring.
V-belt drive:
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual.
"5-year European warranty, you won't find anything comparable"

Transportable breathing air compressor as marine version for 200 or 300 bar, stable STAINLESS STEEL frame, powder-coated, with likewise powder-coated stainless steel transport handles.
AUTO-STOP on reaching the final pressure included as standard.
Air flow rate 150 L/min, 9 m³h, 5.3 cfm.
3-cylinder, 3-stage compressor block, 1st - 2nd - 3rd stage with safety valve. Aluminum cylinders, some with cast iron liners, aluminum pistons with special piston rings for long service life, free-floating pistons in last stage. 2 condensation water separators with bleed valve, oil slinger pin safety lubrication. Micronic suction filter, final pressure gauge. 1 filling connection DIN 200 or 300 bar with venting on 1.2 m hose. Triple+ pure dryer system FT 100 for approx. 130 m³ of pure air in accordance with DIN 12021:2014 (provided the value for CO2 in the intake air complies with the limit values)
Optionally with Airsave Basic filter saturation and service interval monitoring.
V-belt drive:
Included in the scope of delivery: Triple+dryer cartridge FT 100, compressor oil, user manual, parts manual.
"5-year European warranty, you won't find anything comparable"

Transportabler Atemluftverdichter, stabiler Rahmen, pulverbeschichtet, Transportgriffe.
Luftliterleistung 210-250 L/Min., 12,6-15 m³ H, 7,42-8,83 cfm.
3-stufiger Kompressorblock, jede Stufe mit Sicherheitsventil. Speziell gehohnte Graugusszylinder, Aluminium-Kolben mit Spezialkolbenringen, Freiflugkolben in letzter Kompressionsstufe, Niederdruck-Ölpumpe mit Ölfilter für sichere Schmierung, Micronic- Ansaugfilter, Enddruckmanometer, Druckhalteventil, Rückschlagventil,
automatische Enddruckabschaltung,
ein Füllanschluss an 1,0 mtr. Schlauch mit entlüftbarer 200 oder 300 bar Füllarmatur. TriplePlus Reintrocknersystem FT 160 für ca. 600 m³ reine Luft nach DIN EN 12021,
Antrieb mittels Keilriemen: 1 Phasen-Wechselstrommotor 4 kW, 230 V, 50 Hz , oder 3-Phasen Drehstrom 4-5,5-kW 400V 50/60Hz.Geräuschentwicklung ca. 83 dbA.
Im Lieferumfang: Tripletrocknerpatrone FT 160, Kompressoröl, ausführliches Handbuch, Kompressor Logbuch, Füllbuch.
Dimensionen: LBH 100 x 45 x 68 cm, Gewicht 125 kg.

Transportabler Atemluftverdichter, stabiler pulverbeschichteter Stahl-Sturzrahmen mit klappbaren Transportgriffen.  Luftliterleistung 200-250 -300 L/Min, 12- 18 m³/h, 7,06- 8,83- 10,6 c.f.m., wahlweise 200 oder 300 bar.  3-stufiger Kompressorblock, jede Stufe mit Sicherheitsventil, mit hochabriebfesten spezialgehohnten Grauguss Zylinder- Laufbuchsen, Kolben mit Spezialkolbenringen, Edelstahlzwischenkühler, Schmierung mit Niederdruckölpumpe). Der Kolben der 3. Stufe arbeitet als Freiflugkolben, Micronic- Ansaugfilter, Enddruckmanometer, Druckhalteventil, Rückschlagventil, AutoStop bei erfreichen des Enddrucks, automatische zeitgesteuerte Kondensatableitung mit Sammelkanister.
2 Füllschläuche 1,2 mtr. mit Handgriff und entlüftbarer Füllarmatur  DIN 200 oder 300 bar je nach Bestellung.
Triple-Plus Reintrocknersystem FT 160   für ca. 600 m³ (@20°C), reine Luft nach DIN EN 12021:2014, (bei entsprechender Ansaugluft mit zugelassenem CO2 Gehalt)   Druckhalteventil für längere Patronenstandzeiten.
Optional AIRSAVE PRO E Trocknerpatronen-sättigungs-Überwachung
V-belt drive:
Drehstrom 4 kW, 230V Wechselstrom oder Drehstrom 400 V, 50/60 Hz, Wahlweise auch mit Benzinmotor HONDA GX 270. Geräuschentwicklung ca. 83 dbA, mit Hondamotor ca 95 db(A) in 1,5 mtr. Entfernung.
Control:
Bavaria High End Stern-Dreieck Steuerung. Haupttrennaschalter, Not-Aus Pilz Taster, Display mit Touch-buttons für Start/Stop, Kontrollleuchten für Betrieb, automatische  Kondensatableitung mit Sammelkanister, automatische Enddruckabschaltung, Wartungsintervall-Überwachung, Betriebsstundenzähler. Im Lieferumfang enthalten:
1x Trocknerpatrone FT 160, Kompressoröl, ausführliches Handbuch, Teilehandbuch, Kompressorlogbuch, Füllbuch und Zertifikate.
Optionally available at an extra charge:
2nd pressure range for simultaneous filling, additional filling hoses (max. 4 possible),
Maße: 132 x 59 x 64 cm, Gewicht: ca. 141 kg.

Transportabler Atemluftverdichter, in robustem Sturzrahmen, pulverbeschichtet mit Transportgriffen.  Luftliterleistung 320 L/Min, 19,2 m³/h, 11,3 c.f.m., 200 bar. Hochmoderner 3-stufiger Kompressorblock, jede Stufe mit Sicherheitsventil, Zylinder mit hochabriebfesten spezialgehohnten Laufbuchsen für absolut geringen Ölverbrauch, Kolben mit Spezialkolbenringen, Edelstahlzwischenkühlern, Schmierung, hocheffiziente Schleuderstiftschmierung. Der Kolben der 3. Stufe arbeitet als Freiflugkolben, Micronic- Ansaugfilter, Enddruckmanometer, Druckhalteventil, Rückschlagventil,
2 Füllschläuche 1,2 mtr. mit Handgriff und entlüftbarer Füllarmatur  2x DIN 200 bar. Triple-Plus Reintrocknersystem FT 160  für ca. 600 m³ (@20°C), reine Luft nach DIN EN 12021:2014, (bei entsprechender Ansaugluft mit zugelassenem CO2 Gehalt)   Druckhalteventil für längere Patronenstandzeiten.
Automatische Kondensatableitung und automatische Enddruckabschaltung.
Optional AIRSAVE Basic which monitors the dryer cartridge saturation and the service intervals and at the same time records the operating hours.
V-belt drive:
HONDA GX 270 6.3kW-8.4HP. Noise emission approx. 91 dbA at 1.5 mtr. distance.
1x Trocknerpatrone FT 160 H, Kompressoröl, ausführliches Handbuch, Teilehandbuch, Kompressorlogbuch, Füllbuch und Zertifikate.
Maße: 1235mm*590mm*660mm cm, Gewicht: ca. 134 kg.
